| NETWORK STANDARDS : |
802.11n wireless LAN | 802.11g wireless LAN | 802.11b wireless LAN | 802.3/802.3u 10BASE-T/100BASE-TX Ethernet | ANSI/IEEE 802.3 NWay auto-negotiation |
| DEVICE INTERFACES : |
802.11g/n wireless LAN | One 10/100BASE-TX Ethernet LAN port |
| OPERATING FREQUENCY : |
2.4 to 2.4835ghz |
| OPERATING MODES : |
Access Point | Wireless Client | Bridge | Bridge with AP Repeater | WISP Client Router | WISP Repeater |
| SECURITY : |
64/128-bit WEP data encryption | WPA-PSK, WPA2-PSK | WPA-EAP, WPA2-EAP | TKIP, AES | MAC address filtering | SSID broadcast disable function | WPS (Wi-fi Protected Setup) |
| DEVICE MANAGEMENT : |
Web-based management through Microsoft Internet Explorer 6 or higher,firefox 1.5 or higher, or other Java-enabled browser |
| DIAGNOSTIC LEDS : |
Power | Wireless | Security | LAN |
| POWER INPUT : |
5V DC/1.2 A external power adapter |
| DIMENSIONS (WxDxH) : |
147.5 x 113 x 31.5 mm(5.81 x 4.45 x 1.24 inches) |
| CERTIFICATIONS : |
FCC Class B | CE | Wi-fi b/g/n |
