| Interface : |
4 10/100Mbps LAN Ports 1 10/100Mbps WAN Port |
| Button : |
Reset Button WPS/Wi-Fi On/Off Button Power On/Off Button |
| External Power Supply : |
9VDC / 0.85A |
| Dimensions ( W x D x H ) : |
9.1 x 5.7 x 1.5 in. (229.87 x 144.19 x 36.85 mm) |
| Antenna Type : |
4 External Antennas |
| Wireless Standards : |
IEEE 802.11n/g/b 2.4GHz IEEE 802.11ac/n/a 5GHz |
| Frequency : |
2.4GHz and 5GHz |
| Signal Rate : |
2.4GHz: Up to 300Mbps 5GHz: Up to 867Mbps |
| Reception Sensitivity : |
5GHz: 11a 54M: -73dBm 11ac VHT20 MCS8: -68dBm 11ac VHT40 MCS9: -64dBm 11ac VHT80 MCS9: -60dBm 2.4GHz: 11g 54M: -76dBm 11n HT20 MCS7: -74dBm 11n HT40 MCS7: -71d |
| Transmit Power : |
CE: |
| Wireless Functions : |
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
| Wireless Security : |
64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption |
| Product Id : |
TLC50 |
